Manufacturer: Analog Devices Inc.
Product Category: Analog to Digital Converters - ADC
RoHS: Compliant
Series: AD9643
Mounting Style: SMD/SMT
Package / Case: LFCSP-64
Resolution: 14 bit
Number of Channels: 2 Channel
Interface type: Parallel, SPI
Sampling ratio: 250 MS/s
Input type: Differential
Structure: Pipeline
Analog supply voltage: 1.8 V
Digital supply voltage: 1.8 V
SNR - Signal to Noise Ratio: 72 dB
Minimum operating temperature: - 40 C
Maximum operating temperature: + 85 C
Package: Tray
Trademark: Analog Devices
DNL - Differential Nonlinearity: +/- 0.75 LSB
Gain error: +/- 4 %FSR
Height: 0.83 mm
INL - Integral nonlinearity: +/- 3.5 LSB
Input voltage: 1.75 Vp-p
Length: 9 mm
Humidity sensitivity: Yes
Number of ADC inputs: 2 Input
Number of Converters: 2 Converter
Operating supply voltage: 1.8 V
Output Type: LVDS
Pd-Power Dissipation: 785 mW
Power consumption: 770 mW
Product Type: ADCs - Analog to Digital Converters
Reference Type: Internal
Sample and Hold: Yes
Package Quantity: 260
Subcategory: Data Converter ICs
Supply Voltage - Max: 1.8 V
Supply Voltage - Min: 1.8 V
Type: S/H ADC
Width: 9 mm
Unit weight: 454 mg
